High Quality Cast Pipe Fittings and Camlock Couplings

High Quality Cast Pipe Fittings and Camlock Couplings

High-quality cast pipe fittings and cam-locking couplings are indispensable core components of fluid transport systems, forming the cornerstone of stable, safe, and efficient operation across various industries. These products undergo rigorous material selection, precision manufacturing, and quality control, demonstrating exceptional durability, sealing performance, and adaptability to harsh operating conditions, providing reliable solutions for diverse industrial and infrastructure needs.

Our cast pipe fittings are predominantly made of high-grade ductile iron
(such as QT420-5/QT500-7) and gray cast iron, undergoing advanced
spheroidization treatment to ensure graphite is evenly distributed in a
spherical form. This structural optimization significantly enhances mechanical
properties, with tensile strength reaching over 420 MPa and yield strength not
less than 300 MPa, delivering exceptional load-bearing capacity and resistance
to deformation . Covering a full range of specifications from DN80 to DN2600, we
adopt tailored manufacturing processes for different sizes: high-pressure
molding and resin sand core casting for DN300 and below, and lost foam vacuum
casting for DN300 and above, paired with sophisticated wire feeding
spheroidization technology to guarantee superior surface finish, precise
dimensional accuracy, and consistent mechanical performance .

To ensure long-term reliability, every fitting undergoes 100% hydrostatic
testing (at 1.5 times the working pressure), 100% anti-corrosion treatment, and
100% compliance with hygiene standards for inner linings . The inner wall is
coated with cement mortar, epoxy, or 316L stainless steel, while the outer wall
features a dual-protection layer of zinc coating plus asphalt paint or
polyurethane, effectively resisting corrosion from sewage, chemicals, and harsh
soil environments . All products adhere to international standards including ISO
2531, EN 545, GB/T 13295, and AWWA C153, passing rigorous inspections such as
chemical composition analysis, mechanical property testing, non-destructive flaw
detection, and salt spray corrosion resistance testing through CNAS-certified
laboratories .

Widely applied in water supply and drainage, municipal engineering,
petrochemical, and construction industries, these fittings (including elbows,
tees, reducers, and flanges) are ideal for underground sewer lines, stormwater
drainage systems, industrial fluid pipelines, and large-scale building plumbing.
They seamlessly integrate with pipes of various pressure classes (such as K0,
K9, K11, K12) and maintain structural integrity even under high soil loads,
traffic pressure, and temperature fluctuations .
