Black K Type Spider Fitting
The Black K Type Spider Fitting is a three-arm point-fixed glass connector engineered for corner and edge applications in modern glass facade systems.
The Black K Type Spider Fitting is a three-arm point-fixed glass connector engineered for corner and edge applications in modern glass facade systems. As a variant of the standard spider fitting family, the "K" configuration features two arms aligned at 180° (forming a straight line) and a third arm positioned at 90° — creating a silhouette that resembles the letter "K". This geometry makes it the ideal fitting for L-shaped glass corners, skylight ridges, and facade perimeter details where a four-way cross spider would be unnecessary or visually intrusive.
The "Black" designation refers to a premium dark surface finish — most commonly achieved through PVD (Physical Vapor Deposition) coating, black anodizing, or fluoropolymer powder coating — applied over a 304 or 316 stainless steel substrate. The black finish delivers a sleek, contemporary aesthetic while maintaining the corrosion resistance and structural integrity of stainless steel, making it a favored choice for high-end architectural projects where hardware must either recede visually or serve as a deliberate design accent.
Key Features
-
K-Profile Geometry — 180° + 90° three-arm layout purpose-built for glass corners, edges, and skylight ridges
-
Premium Black Finish — PVD black coating, black anodize, or fluorocarbon powder coat for a uniform, durable dark surface
-
Articulated Joints — Each arm independently swivels ±15° to accommodate glass deflection, thermal movement, and installation tolerances
-
Stainless Steel Core — 304 or 316 stainless steel substrate beneath the black coating for structural strength and corrosion resistance
-
High Load Capacity — Engineered to withstand wind pressure, dead load, and seismic forces per project specifications
-
Frameless Aesthetic — Minimal visible hardware; black finish further reduces visual weight, allowing glass to dominate the facade
-
Easy Maintenance — Smooth, non-porous coating resists fingerprints, water staining, and environmental soiling
-
Full Compatibility — Interchangeable with standard routels, glass holders, and supporting hardware from the same system family
| Arm Position | Angle | Function |
|---|---|---|
| Arm 1 (Horizontal Left) | 180° from Arm 2 | Secures one glass panel along the straight run |
| Arm 2 (Horizontal Right) | 180° from Arm 1 | Secures the adjacent glass panel in the same plane |
| Arm 3 (Vertical / Perpendicular) | 90° from Arms 1 & 2 | Secures the glass panel on the perpendicular face (corner) |
