2 Color Shuttle Screen Printer

Product Introduction

The 2 Color Shuttle Screen Printer is an automated multi-color printing machine designed for flat products and multidimensional surface printing. It can be connected directly to an injection molding machine, allowing products to move from molding to automated printing with reduced manual handling.

The system combines 4-color screen printing and 2-color transfer printing, providing a total of 6 printing colors to meet the requirements of a wide range of flat printing applications. Except for the bottom surface, the equipment can print on different surfaces of a product, supporting flexible multidimensional decoration.

Driven by a server-controlled automatic loading and unloading system, the machine can connect with an injection molding machine to support unmanned loading and automated production. Its fully servo-driven motion structure provides precise movement, convenient machine debugging, and stable printing performance.

Key Product Features

Automated Injection Molding Machine Connection

The printer can be integrated with an injection molding machine to create an automated production line. Finished products can be transferred directly from the injection molding process to the printing process, reducing manual loading and improving production efficiency.

6-Color Printing Capability

The system combines 4 screen printing colors with 2 transfer printing colors, providing a total of 6 colors. This configuration offers greater flexibility for multi-color product decoration and can accommodate diverse flat printing requirements.

Multi-Dimensional Surface Printing

The equipment can print on almost any product surface except the bottom, making it suitable for products requiring printing on multiple planes or different surface areas.

Automatic Loading and Unloading

The server-driven loading and unloading system can automatically transfer products and connect with injection molding equipment, helping reduce manual operation and supporting continuous automated production.

Accurate Color Matching

The server control system is designed to improve color matching accuracy, helping maintain consistent printing results during production.

Full Servo Motion Control

A fully servo-driven motion structure provides precise machine movement and improves positioning accuracy. It also makes machine adjustment and debugging more convenient.

UV Curing Options

After printing, the machine can be equipped with LCD UV cold-light curing or electronic UV curing according to production requirements, helping complete the curing process efficiently.

Remote Program Debugging

A private communication server supports remote program debugging, allowing production programs to be adjusted and maintained more conveniently.

PLC Touch Screen Control

The complete machine is controlled by a PLC system with a touch screen display. The interface is designed for straightforward operation, while recipe parameters can be read or saved with one click for convenient production management.

Product Advantages

• Automatic connection with injection molding machines

• 4 screen printing + 2 transfer printing, up to 6 colors

• Printing on multiple product surfaces except the bottom

• Automatic loading and unloading

• Support for unmanned automated production

• Servo-driven motion system

• Improved printing positioning accuracy

• Enhanced color matching control

• LCD UV cold-light or electronic UV curing options

• Remote program debugging through a private communication server

• PLC control with touch screen operation

• One-click recipe parameter reading

• One-click recipe parameter saving

• Suitable for high-efficiency multi-color printing

Technical Specifications

Printing System

The printing configuration consists of 4 screen printing colors and 2 transfer printing colors, providing a total of 6 colors. This combination is designed for products requiring multi-color graphics, logos, patterns, text, or decorative elements.

The equipment supports printing on different surfaces of flat products, except the bottom surface. Its multidimensional printing capability makes it suitable for applications where conventional single-plane printing equipment may not provide sufficient surface coverage.

Automation and Production Integration

The 2 Color Shuttle Screen Printer can be integrated with injection molding equipment for automated production. Products can be automatically transferred from molding to the printing station, reducing intermediate handling and manual loading operations.

The automatic loading and unloading system is driven by the server and can support continuous product transfer. Combined with PLC control and recipe management, the machine is suitable for production environments where repeatability, automation, and reduced labor intervention are required.

Control and Operation

The PLC-based control system uses a touch screen interface for convenient operation and production management.

Operators can quickly access stored recipe parameters and save new parameters with one-click functions. This helps simplify product changeovers and makes it easier to manage different printing programs.

The private communication server also enables remote program debugging, providing an additional option for equipment maintenance and technical support.

UV Curing System

The printing system can use LCD UV cold-light curing or electronic UV curing after printing. With a UV power specification of 280 W, the curing system is designed to support efficient post-printing treatment according to the selected configuration and production requirements.

Optional Configuration

The fixture can be equipped with an inflation or suction function according to the product and production requirements.

This optional fixture configuration can help improve product positioning and handling during automated printing, particularly when the product geometry or production process requires additional holding support.

Application

This machine is suitable for flat products requiring automatic multi-color printing. It can print multiple surfaces of the product except the bottom and is suitable for applications requiring flexible multidimensional decoration.

Typical application requirements include:

• Flat product printing

• Multi-color product decoration

• Logo and graphic printing

• Text and pattern printing

• Multi-surface printing

• Injection molded product decoration

• Automated printing production lines

• High-volume industrial printing

• Unmanned or low-manpower production

Why Choose This Automatic Screen Printing Solution?

The combination of injection molding integration, automatic loading and unloading, six-color printing capability, servo motion control, PLC operation, and UV curing makes this equipment suitable for manufacturers looking to improve printing automation.

Instead of manually transferring molded products between different processes, the system can connect printing with injection molding and streamline product handling. Its multi-color printing configuration also provides greater flexibility for decorative requirements.

For manufacturers producing different product designs, the recipe management function makes it easier to save and retrieve printing parameters, while the servo structure supports precise machine movement and convenient adjustment.

Product Summary

The 2 Color Shuttle Screen Printer offers an integrated solution for automated multi-color printing, combining screen printing, transfer printing, servo control, automatic handling, and UV curing in one production system.

With support for up to six printing colors and printing on multiple surfaces, it provides flexible decoration capabilities for flat injection molded products. The machine is particularly suitable for manufacturers seeking automated production, consistent printing quality, and reduced manual handling.

Contact Supplier

For specifications, configuration options, application requirements, or customized printing solutions, contact Shenzhen Kar Lee Keung Electronic Equipment Ltd. to discuss your production needs.

The team can provide information on machine configuration, fixture options, printing requirements, automation integration, and suitable curing solutions.

For reliable automated multi-color product decoration, the 2 Color Shuttle Screen Printer is designed to provide flexible printing capability, efficient product handling, and convenient production control.
